BURSTING STRENGTH TESTER FOR PAPER BOARD & CORRUGATED BOAR(CLAMPING THROUGH HAND WHEEL)

BURSTING STRENGTH TESTER FOR PAPER BOARD & CORRUGATED BOAR(CLAMPING THROUGH HAND WHEEL)

UEC-1010 B1


This is the optimum equipment for determining the bursting strength of paperboard, corrugated board or solid fiberboard material. The specimen is tightened by screw clamping through rotation of wheel handle. The bursting pressure, at the time of rupture is recorded on a sensitive pressure gauge which indicates the test results in Kg /Cm² or in PSI units. Measuring Range - 0 to 50 Kg./cm².

Accessories on Demand:

“Rubber Membrane Diaphragms”

“Standard Reference Testing Foils”

“Glycerol Fluid”

“Double Pressure Gauge Assembly for fitting of Extra Bourdon Pressure Gauge”

“Standard Pressure Gauges with Set Point Indicator, Range 0 - 10/14/21/42/70 Kg/cm².”

Product Code UEC-1010 B1
Equipment Category Physical Property Testing Equipments
Weight

50.500 Kg.

Dimension

55.0 x 64.0 x 44.5 cm.

Applicable Standards

SCAN P 24, P 25, TAPPI T403, T807, T810, CPPA D.8, ISO 2758, 2759, FEFCO No.4, BS 3137, JIS 8112, ASTM D 751, D 3393.
