OIL PENETRATION TESTER (WILLIAM TYPE)

OIL PENETRATION TESTER (WILLIAM TYPE)

UEC-1022


This Equipment is used for determining the Impregnation (Penetration) Time of Oil and other Liquids, which may be defined as, the Time in Seconds required for a Liquid of Definite Composition and Viscosity to Completely Penetrate the Sheet of Paper, from one face to the other, under certain specified conditions. The Penetration is checked for paper and other similar materials, used for Lamination purpose. The UEC Castor Oil Penetration Tester (COP) is provided with cooling system, Electronic PID Controller for constant Temperature Regulation and Castor Oil (Impregnating Liquid).

Accessories on Demand:

"Self Starting Digital Timer" for measurement of Penetration Time in Seconds. Measuring range up to 99,999 Seconds.

Product Code UEC-1022
Equipment Category Physical Property Testing Equipments
Weight

7.0 Kg.

Dimension

Main Unit - 38.0 x 15.5 x 21.5 cm.  Digital Timer - 29.0 x 20.5 x 14.0 cm.

Applicable Standards

TAPPI T462 om-01, ASTM.
