TENSILE TESTER ELECTRONIC (SINGLE COLUMN)

TENSILE TESTER ELECTRONIC (SINGLE COLUMN)

UEC-1005 B


This Single Column Tensile Tester is Microprocessor Based with LCD Display and operational through Key Pad. It provides rapid and efficient determination of Tensile Strength, Stretch (Elongation) & Breaking Length (BL) of Paper, Tissue Paper and Paperboard.

For testing of Tissue Papers, Load Cell of low capacity & specially designed Soft Clamps are provided which prevent Test Pieces from Slipping or Tearing during measurements. The Equipment is provided with the standard “Sample Clamping Jaws” of 15 mm Size.

Extra on Demand:

 “Sample Preparation Cutter (Sample Size 15 mm / 25 mm OR 50 x 300 mm)”

 “Sample Clamping Jaws of 25 mm OR 50 mm Size”

 “Load Cell of Capacity 05/10/20/50 Kgf. (50/100/200/500 N)”

 “Standard Calibration Check Weights”

 “Thermal Printer to Print the Instant Test Data”

 “Finch Device for Wet Tensile Test”

Product Code UEC-1005 B
Equipment Category Physical Property Testing Equipments
Weight

34.5 Kg

Dimension

37.5 x 45.5 x 96.0 cm.

Applicable Standards

ISO 3035, 7263, 3037, 536, 1924, TAPPI T 822, T 809, T 410, T 494

Range Available
